Acid & Alkali Resistant Pump for Chemical Industries
|Terms of Trade:||FOB,CFR,CIF,EXW|
|Min. Order:||1 Set/Sets|
|Delivery Time:||60 Days|
|Packaging:||Wooden case or Frame steel Case|
|Place of Origin:||Zigong,Sichuan,China|
|Supply Ability:||110000 sets/month|
Model No.: ZBG65-50-125
ZB series chemical process pump including ZBG(closed impeller type), ZBK(semi-open impeller type) and ZBQ(fully-open impeller type). It is an elaborately developed chemical process pump of new generation which absorbed the advanced technology of both home and aboard,and eliminated the technical defects of IH and CZ chemical process pump,with the advantages of better anti-cavitation performance, stable sealing performance, smooth operation and easy maintenance. The high interchangeability,transforming structures and various anti-corrosive materials satisfy the requirements of different applications,and therefore is widely used.
|Flow rate:||Q= 2~2050 (m³/h)|
|Total head:||H=3~150 (m)|
- Conform to ISO2858(GB5662)and GB/T5656(equivalent to ISO5199)
- Heavy shaft of increased diameter, the bearing capacity of bearings is averagely increased by 75~160%, the life of bearings are tremendously extended.
- Forced internal cooling cartridge mechanical seal and big sealing chamber reduced the possibility of breakdown.
- Easy adjust method of pump rotor part to maintain low pressure of sealing chamber, to reduce the axial force,and therefore guaranteed the stable operation of pump.
- Several transforming designs enlarged the range of application of pump, increased the reliability of pumping special fluids.
- High interchangeability of pump parts reduced the cost on spares parts for clients.
- Single stage,single suction,horizontal centrifugal pump. Bracket structure for bearing parts, the bearing housing is supported by the bracket. The axial displacement of pump rotor part can be adjusted by a special bolt. Closed impeller(ZBG type),semi-open impeller(ZBK type) and fully opened impeller(ZBQ type) are available.
- The impeller is connected with shaft by screw thread, an anti-vortex plate is adopted at the pump inlet to increase the reliability of pump.
- The impeller with rear blades is adopted to balance the axial force at the pump suction. And the gap between the rear blades of impeller and pump cover can be adjusted by a bolt.
- The pump structure is back pull type,the rotor part(impeller,shaft,shaft sealing and bearings) can be removed without dismantling the pipes during maintenance.
- The shaft sealing is cartridge mechanical seal, and can be customized as single mechanical seal, packing sealing and secondary impeller+packing sealing.
ZB series chemical process pump is suitable to pump clean fluids, fluids with small quantity of small particles and corrosive fluids. The fluids including: inorganic acid,organic acid, petrochemical fluids,organic compounds and other corrosive fluids. The ZB series pump is mainly applicable for:
- Refinery,petrochemical industries,coal mine process industry and low temperature projects.
- Chemical industry,paper-making,paper pulp industry,sugar industry.
- Water treatment plant, seawater desalination projects
- Power plant
- Environment protection projects
- Vessel and offshore industries.
Sichuan Zigong Industrial Pump Co.,Ltd.
Sichuan Zigong Industrial Pump Co., Ltd. (referred to as"ZG Pump") was founded in 1967. It is the earliest key enterprise in the production of impurity pumps and corrosion-resistant pumps. It is the largest industrial pump manufacturing based in Western China with the largest variety and specifications. The company's leading products include impurity pumps, chemical pumps, clean water pumps, hydraulic turbines and bottom-mounted propellers. There are 41 series and more than 600 varieties. The products serve petroleum, metallurgy, chemical, mining, textile and environmental protection, power and municipal facilities and other fields. The company is located in Zigong National High-tech Industrial Development Zone, covering an area of more than 400 acres. It is a pump manufacturer integrating research, production, sales and general contracting services to provide customers with the best solution for fluid transportation.
- Company Name: Sichuan Zigong Industrial Pump Co.,Ltd.
- Representative: WU DEHUA
- Product/Service: Axial pump , Chemical pump , Slurry pump , Water pump , Process pump , Industrial pump
- Capital (Million US $): 200000000RMB
- Year Established: 2005
- Total Annual Sales Volume (Million US $): US$1 Million - US$2.5 Million
- Export Percentage: 1% - 10%
- Total Annual Purchase Volume (Million US $): Below US$1 Million
- No. of Production Lines: 5
- No. of R&D Staff: 31 -40 People
- No. of QC Staff: 11 -20 People
- OEM Services Provided: no
- Factory Size (Sq.meters): 10,000-30,000 square meters
- Factory Location: No.66 Jinchuan Road,Hi-tech Industrial Park,Zigong,Sichuan,China
- Contact Person: Ms. Ivy
- Tel: 86-813-8269991
